MsSqlMCP
About
MCP to query SQL Server database schema, such as tables, columns, and relationships
Details
- License
- Apache-2.0
Explore
- Read-only access: All queries are validated to prevent data modification (INSERT, UPDATE, DELETE, DROP, EXEC, etc. are blocked)
- Schema discovery: Tables, columns, relationships, and stored procedures
- SQL execution: Safe SELECT queries only
- Dual transport: Supports both stdio and HTTP/SSE protocols
- Windows Service: Can run as a Windows Service for production deployments
- MCP Protocol: Compatible with VS Code Copilot, Claude Desktop, and other MCP clients
- .NET 10 (or .NET 9 with minor adjustments)
- SQL Server
Edit C:\Services\MsSqlMCP\appsettings.json with your SQL Server connection string:
{
"ConnectionStrings": {
"DefaultConnection": "Data Source=YOUR_SQL_SERVER;Initial Catalog=YOUR_DATABASE;Encrypt=False;Trusted_Connection=True;MultipleActiveResultSets=true"
},
"Urls": "http://localhost:5000"
}
Open PowerShell as Administrator and run:
net stop MsSqlMCP
sc.exe delete MsSqlMCP
GetTables
Get all table names in the database
GetColumns
Get columns (fields) for a specific table
GetRelationships
Get foreign key relationships between tables
GetStoreProcedure
Get stored procedure definition
ExecuteSql
Execute a read-only SELECT query
| Tool | Description | Required Parameters |
|------|-------------|---------------------|
| GetTables | Get all table names in the database | None |
| GetColumns | Get columns (fields) for a specific table | tableName |
| GetRelationships | Get foreign key relationships between tables | None |
| GetStoreProcedure | Get stored procedure definition | spName |
| ExecuteSql | Execute a read-only SELECT query | sqlQuery |
All tools accept an optional databaseName parameter to query different databases in the same SQL Server instance.
MCP Server for SQL Server database schema inspection and read-only query execution.
Features
- Read-only access: All queries are validated to prevent data modification (INSERT, UPDATE, DELETE, DROP, EXEC, etc. are blocked)
- Schema discovery: Tables, columns, relationships, and stored procedures
- SQL execution: Safe SELECT queries only
- Dual transport: Supports both stdio and HTTP/SSE protocols
- Windows Service: Can run as a Windows Service for production deployments
- MCP Protocol: Compatible with VS Code Copilot, Claude Desktop, and other MCP clients
Prerequisites
- .NET 10 (or .NET 9 with minor adjustments)
- SQL Server
Architecture
The project follows SOLID principles with dependency injection:
MsSqlMCP/
├── Program.cs # Entry point with DI and dual transport
├── SchemaTool.cs # MCP tool definitions
├── Interfaces/
│ ├── IConnectionFactory.cs # SQL connection abstraction
│ ├── IQueryExecutor.cs # Query execution abstraction
│ ├── ISchemaRepository.cs # Schema queries abstraction
│ └── ISqlQueryValidator.cs # Query validation abstraction
├── Services/
│ ├── SqlConnectionFactory.cs # Connection management
│ ├── SafeQueryExecutor.cs # Validated query execution
│ ├── SchemaRepository.cs # Schema query implementation
│ └── ReadOnlySqlQueryValidator.cs # Security validation (27 blocked keywords)
└── Tests/
└── ReadOnlySqlQueryValidatorTests.cs # 42 security tests
Configuration
Connection String
Edit appsettings.json:
{
"ConnectionStrings": {
"DefaultConnection": "Data Source=(local);Initial Catalog=YourDatabase;Encrypt=False;Trusted_Connection=True;MultipleActiveResultSets=true"
},
"Urls": "http://localhost:5000"
}
Running
Console Mode (Development)
```bash
