Read MySQL

by benborla

279 stars

31.3k downloads

Not rated

GitHub

About

Access MySQL databases to inspect schemas and execute SQL queries via a NodeJS-based server.

Details

Author: benborla
Repository: benborla/mcp-server-mysql
GitHub stars: 279
Downloads: 31,345
License: MIT License
Categories: Database, Other, Design, Developer Tools, AI, Security, Frontend
Tags: #mobile

- Read-only by default — write operations opt-in via env flags
- Claude Code integration — optimized for Anthropic's Claude Code CLI
- SSH tunnel support — built-in support for remote databases
- Multi-DB mode — query across multiple databases without reconnecting
- Schema-specific permissions — per-database read/write control
- PII redaction — automatic masking of sensitive data in results
- Remote mode — HTTP transport with bearer token auth
- SSL/TLS support — encrypted connections with mTLS option

Setting up with Highlight

This MCP is not yet compatible with Highlight’s one-click setup. However, you can still use it with Highlight by following these steps:

Download and install Highlight from highlightai.com/download
Navigate to the plugins tab and select "Add Custom Plugin"
Configure the plugin with the settings below
Plugin Name Read MySQL

Command (node, npx, python, etc.) npx
Arguments
- Argument 1 -y
- Argument 2 @benborla29/mcp-server-mysql
Environment
- MYSQL_DB your_database
- MYSQL_HOST 127.0.0.1
- MYSQL_PASS your_password
- MYSQL_PORT 3306
- MYSQL_USER root
Please refer to the README for specific instructions on how to obtain API keys or other required environment variables.
Enable "Start Automatically" if you want the plugin to start when Highlight launches

Setting up with Cursor

Open Cursor's settings
Navigate to the MCP section
Click "Add new Global MCP server"
Copy and paste the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "/c",
                "npx",
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "cmd"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

Setting up with Claude Desktop

Open Claude Desktop's settings
Go to the Integrations tab
Click "Add MCP Server"
Use the configuration below based on your operating system

Note: Make sure Claude Desktop is running before attempting to connect.

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "/c",
                "npx",
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "cmd"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

Setting up with Windsurf

Open Windsurf's preferences
Go to the Integrations section
Click "Add MCP Integration"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "/c",
                "npx",
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "cmd"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

Setting up with Cline

Open Cline's settings
Navigate to the Integrations section
Click "Add MCP Server"
Copy and paste the configuration below based on your operating system

Note: Make sure to restart Cline after adding the configuration.

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "/c",
                "npx",
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "cmd"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

Setting up with Goose

Open Goose's preferences
Go to the Integrations tab
Select "MCP Servers"
Click "Add New Server"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "/c",
                "npx",
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "cmd"
        }
    }
}

JSON

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

From the repository

Claude Code (simplest):

claude mcp add mcp_server_mysql \
  -e MYSQL_HOST="127.0.0.1" \
  -e MYSQL_PORT="3306" \
  -e MYSQL_USER="root" \
  -e MYSQL_PASS="your_password" \
  -e MYSQL_DB="your_database" \
  -- npx @benborla29/mcp-server-mysql

Claude Desktop / other clients:

{
  "mcpServers": {
    "mcp_server_mysql": {
      "command": "npx",
      "args": ["-y", "@benborla29/mcp-server-mysql"],
      "env": {
        "MYSQL_HOST": "127.0.0.1",
        "MYSQL_PORT": "3306",
        "MYSQL_USER": "root",
        "MYSQL_PASS": "your_password",
        "MYSQL_DB": "your_database"
      }
    }
  }
}

All write operations are disabled by default. Enable with ALLOW_INSERT_OPERATION=true, ALLOW_UPDATE_OPERATION=true, ALLOW_DELETE_OPERATION=true.

`mysql_query`

Execute SQL queries. Read-only by default. Write operations enabled per flag.

Claude Desktop / Cursor

Paste into your MCP client config file to install this server.

{
    "mcpServers": {
        "read mysql": {
            "env": {
                "MYSQL_DB": "your_database",
                "MYSQL_HOST": "127.0.0.1",
                "MYSQL_PASS": "your_password",
                "MYSQL_PORT": "3306",
                "MYSQL_USER": "root"
            },
            "args": [
                "-y",
                "@benborla29/mcp-server-mysql"
            ],
            "command": "npx"
        }
    }
}

Linux

{
    "env": {
        "MYSQL_DB": "your_database",
        "MYSQL_HOST": "127.0.0.1",
        "MYSQL_PASS": "your_password",
        "MYSQL_PORT": "3306",
        "MYSQL_USER": "root"
    },
    "args": [
        "-y",
        "@benborla29/mcp-server-mysql"
    ],
    "command": "npx"
}

Macos

{
    "env": {
        "MYSQL_DB": "your_database",
        "MYSQL_HOST": "127.0.0.1",
        "MYSQL_PASS": "your_password",
        "MYSQL_PORT": "3306",
        "MYSQL_USER": "root"
    },
    "args": [
        "-y",
        "@benborla29/mcp-server-mysql"
    ],
    "command": "npx"
}

Windows

{
    "env": {
        "MYSQL_DB": "your_database",
        "MYSQL_HOST": "127.0.0.1",
        "MYSQL_PASS": "your_password",
        "MYSQL_PORT": "3306",
        "MYSQL_USER": "root"
    },
    "args": [
        "/c",
        "npx",
        "-y",
        "@benborla29/mcp-server-mysql"
    ],
    "command": "cmd"
}

# MCP Server for MySQL [![MCP Toplist](https://mcptoplist.com/badge/glama%2Fbenborla%2Fmcp-server-mysql.svg)](https://mcptoplist.com/server/glama%2Fbenborla%2Fmcp-server-mysql) [![Trust Score](https://archestra.ai/mcp-catalog/api/badge/quality/benborla/mcp-server-mysql)](https://archestra.ai/mcp-catalog/benborla__mcp-server-mysql) ## Sponsor — Bloome [![Bloome](assets/bloome.png)](https://bloome.im/login?ref=2x7GfeSw) Using mcp-server-mysql to let your AI query MySQL? [**Bloome**](https://bloome.im/login?ref=2x7GfeSw) brings that to your whole team — an AI-agent IM platform where AI agents are members of the chat. Connect your MCP tools and have agents inspect schemas, run queries, and answer data questions for everyone in one thread. Zero local setup, runs in the cloud, on web and mobile. --- MCP server that gives Claude and other LLMs access to MySQL — inspect schemas, run queries, and optionally write data, all through the Model Context Protocol. ## Key Features - **Read-only by default** — write operations opt-in via env flags - **Claude Code integration** — optimized for Anthropic's Claude Code CLI - **SSH tunnel support** — built-in support for remote databases - **Multi-DB mode** — query across multiple databases without reconnecting - **Schema-specific permissions** — per-database read/write control - **PII redaction** — automatic masking of sensitive data in results - **Remote mode** — HTTP transport with bearer token auth - **SSL/TLS support** — encrypted connections with mTLS option ## Requirements - Node.js v20+ - MySQL 5.7+ (8.0+ recommended) - MySQL user with appropriate privileges ## Quick Install **Claude Code (simplest):** ```bash claude mcp add mcp_server_mysql \ -e MYSQL_HOST="127.0.0.1" \ -e MYSQL_PORT="3306" \ -e MYSQL_USER="root" \ -e MYSQL_PASS="your_password" \ -e MYSQL_DB="your_database" \ -- npx @benborla29/mcp-server-mysql ``` **Claude Desktop / other clients:** ```json { "mcpServers": { "mcp_server_mysql": { "command": "npx", "args": ["-y", "@benborla29/mcp-server-mysql"], "env": { "MYSQL_HOST": "127.0.0.1", "MYSQL_PORT": "3306", "MYSQL_USER": "root", "MYSQL_PASS": "your_password", "MYSQL_DB": "your_database" } } } } ``` All write operations are disabled by default. Enable with `ALLOW_INSERT_OPERATION=true`, `ALLOW_UPDATE_OPERATION=true`, `ALLOW_DELETE_OPERATION=true`. ## Documentation - [Installation Guide](docs/INSTALLATION.md) — Smithery, Cursor, Codex, Claude Code, local repo, remote mode - [Configuration & Environment Variables](docs/CONFIGURATION.md) — all env vars, advanced config - [Multi-DB Mode](README-MULTI-DB.md) — querying multiple databases - [PII Redaction](docs/PII-REDACTION.md) — automatic data masking - [Testing](docs/TESTING.md) — test setup and running - [Troubleshooting](docs/TROUBLESHOOTING.md) — common issues and fixes - [Changelog](CHANGELOG.md) ## Tools & Resources **Tool: `mysql_query`** Execute SQL queries. Read-only by default. Write operations enabled per flag. **Resources: `mysql://tables`** Lists all tables and column metadata for the connected database. ## Contributing PRs welcome at [github.com/benborla/mcp-server-mysql](https://github.com/benborla/mcp-server-mysql). ```bash git clone https://github.com/benborla/mcp-server-mysql.git pnpm install pnpm run build pnpm test ``` [![Contributors](https://contrib.rocks/image?repo=benborla/mcp-server-mysql)](https://github.com/benborla/mcp-server-mysql/graphs/contributors) ## License MIT — see [LICENSE](LICENSE) for details.
