# Talk to Figma MCP This project implements a Model Context Protocol (MCP) integration between AI agent (Cursor, Claude Code) and Figma, allowing AI agent to communicate with Figma for reading designs and modifying them programmatically. https://github.com/user-attachments/assets/129a14d2-ed73-470f-9a4c-2240b2a4885c ## Project Structure - `src/talk_to_figma_mcp/` - TypeScript MCP server for Figma integration - `src/cursor_mcp_plugin/` - Figma plugin for communicating with Cursor - `src/socket.ts` - WebSocket server that facilitates communication between the MCP server and Figma plugin ## How to use 1. Install Bun if you haven't already: ```bash curl -fsSL https://bun.sh/install | bash ``` 2. Run setup, this will also install MCP in your Cursor's active project ```bash bun setup ``` 3. Start the Websocket server ```bash bun socket ``` 4. **NEW** Install Figma plugin from [Figma community page](https://www.figma.com/community/plugin/1485687494525374295/cursor-talk-to-figma-mcp-plugin) or [install locally](#figma-plugin) ## Quick Video Tutorial [Video Link](https://www.linkedin.com/posts/sonnylazuardi_just-wanted-to-share-my-latest-experiment-activity-7307821553654657024-yrh8) ## Design Automation Example **Bulk text content replacement** Thanks to [@dusskapark](https://github.com/dusskapark) for contributing the bulk text replacement feature. Here is the [demo video](https://www.youtube.com/watch?v=j05gGT3xfCs). **Instance Override Propagation** Another contribution from [@dusskapark](https://github.com/dusskapark) Propagate component instance overrides from a source instance to multiple target instances with a single command. This feature dramatically reduces repetitive design work when working with component instances that need similar customizations. Check out our [demo video](https://youtu.be/uvuT8LByroI). ## Manual Setup and Installation ### MCP Server: Integration with Cursor Add the server to your Cursor MCP configuration in `~/.cursor/mcp.json`: ```json { "mcpServers": { "TalkToFigma": { "command": "bunx", "args": ["cursor-talk-to-figma-mcp@latest"] } } } ``` ### WebSocket Server Start the WebSocket server: ```bash bun socket ``` ### Figma Plugin 1. In Figma, go to Plugins > Development > New Plugin 2. Choose "Link existing plugin" 3. Select the `src/cursor_mcp_plugin/manifest.json` file 4. The plugin should now be available in your Figma development plugins ## Windows + WSL Guide 1. Install bun via powershell ```bash powershell -c "irm bun.sh/install.ps1|iex" ``` 2. Uncomment the hostname `0.0.0.0` in `src/socket.ts` ```typescript // uncomment this to allow connections in windows wsl hostname: "0.0.0.0", ``` 3. Start the websocket ```bash bun socket ``` ## Usage 1. Start the WebSocket server 2. Install the MCP server in Cursor 3. Open Figma and run the Cursor MCP Plugin 4. Connect the plugin to the WebSocket server by joining a channel using `join_channel` 5. Use Cursor to communicate with Figma using the MCP tools ## Local Development Setup To develop, update your mcp config to direct to your local directory. ```json { "mcpServers": { "TalkToFigma": { "command": "bun", "args": ["/path-to-repo/src/talk_to_figma_mcp/server.ts"] } } } ``` ## MCP Tools The MCP server provides the following tools for interacting with Figma: ### Document & Selection - `get_document_info` - Get information about the current Figma document - `get_selection` - Get information about the current selection - `read_my_design` - Get detailed node information about the current selection without parameters - `get_node_info` - Get detailed information about a specific node - `get_nodes_info` - Get detailed information about multiple nodes by providing an array of node IDs - `set_focus` - Set focus on a specific node by selecting it and scrolling viewport to it - `set_selections` - Set selection to multiple nodes and scroll viewport to show them ### Annotations - `get_annotations` - Get all annotations in the current document or specific node - `set_annotation` - Create or update an annotation with markdown support - `set_multiple_annotations` - Batch create/update multiple annotations efficiently - `scan_nodes_by_types` - Scan for nodes with specific types (useful for finding annotation targets) ### Prototyping & Connections - `get_reactions` - Get all prototype reactions from nodes with visual highlight animation - `set_default_connector` - Set a copied FigJam connector as the default connector style for creating connections (must be set before creating connections) - `create_connections` - Create FigJam connector lines between nodes, based on prototype flows or custom mapping ### Creating Elements - `create_rectangle` - Create a new rectangle with position, size, and optional name - `create_frame` - Create a new frame with position, size, and optional name - `create_text` - Create a new text node with customizable font properties ### Modifying text content - `scan_text_nodes` - Scan text nodes with intelligent chunking for large designs - `set_text_content` - Set the text content of a single text node - `set_multiple_text_contents` - Batch update multiple text nodes efficiently ### Auto Layout & Spacing - `set_layout_mode` - Set the layout mode and wrap behavior of a frame (NONE, HORIZONTAL, VERTICAL) - `set_padding` - Set padding values for an auto-layout frame (top, right, bottom, left) - `set_axis_align` - Set primary and counter axis alignment for auto-layout frames - `set_layout_sizing` - Set horizontal and vertical sizing modes for auto-layout frames (FIXED, HUG, FILL) - `set_item_spacing` - Set distance between children in an auto-layout frame ### Styling - `set_fill_color` - Set the fill color of a node (RGBA) - `set_stroke_color` - Set the stroke color and weight of a node - `set_corner_radius` - Set the corner radius of a node with optional per-corner control ### Layout & Organization - `move_node` - Move a node to a new position - `resize_node` - Resize a node with new dimensions - `delete_node` - Delete a node - `delete_multiple_nodes` - Delete multiple nodes at once efficiently - `clone_node` - Create a copy of an existing node with optional position offset ### Components & Styles - `get_styles` - Get information about local styles - `get_local_components` - Get information about local components - `create_component_instance` - Create an instance of a component - `get_instance_overrides` - Extract override properties from a selected component instance - `set_instance_overrides` - Apply extracted overrides to target instances ### Export & Advanced - `export_node_as_image` - Export a node as an image (PNG, JPG, SVG, or PDF) - limited support on image currently returning base64 as text ### Connection Management - `join_channel` - Join a specific channel to communicate with Figma ### MCP Prompts The MCP server includes several helper prompts to guide you through complex design tasks: - `design_strategy` - Best practices for working with Figma designs - `read_design_strategy` - Best practices for reading Figma designs - `text_replacement_strategy` - Systematic approach for replacing text in Figma designs - `annotation_conversion_strategy` - Strategy for converting manual annotations to Figma's native annotations - `swap_overrides_instances` - Strategy for transferring overrides between component instances in Figma - `reaction_to_connector_strategy` - Strategy for converting Figma prototype reactions to connector lines using the output of 'get_reactions', and guiding the use 'create_connections' in sequence ## Development ### Building the Figma Plugin 1. Navigate to the Figma plugin directory: ``` cd src/cursor_mcp_plugin ``` 2. Edit code.js and ui.html ## Best Practices When working with the Figma MCP: 1. Always join a channel before sending commands 2. Get document overview using `get_document_info` first 3. Check current selection with `get_selection` before modifications 4. Use appropriate creation tools based on needs: - `create_frame` for containers - `create_rectangle` for basic shapes - `create_text` for text elements 5. Verify changes using `get_node_info` 6. Use component instances when possible for consistency 7. Handle errors appropriately as all commands can throw exceptions 8. For large designs: - Use chunking parameters in `scan_text_nodes` - Monitor progress through WebSocket updates - Implement appropriate error handling 9. For text operations: - Use batch operations when possible - Consider structural relationships - Verify changes with targeted exports 10. For converting legacy annotations: - Scan text nodes to identify numbered markers and descriptions - Use `scan_nodes_by_types` to find UI elements that annotations refer to - Match markers with their target elements using path, name, or proximity - Categorize annotations appropriately with `get_annotations` - Create native annotations with `set_multiple_annotations` in batches - Verify all annotations are properly linked to their targets - Delete legacy annotation nodes after successful conversion 11. Visualize prototype noodles as FigJam connectors: - Use `get_reactions` to extract prototype flows, - set a default connector with `set_default_connector`, - and generate connector lines with `create_connections` for clear visual flow mapping. ## License MIT
