Mcp Mysql Server
About
一个提供MySQL数据库操作的模型上下文协议服务器。该服务器使AI模型能够通过标准化接口与MySQL数据库进行交互。支持对数据库的所有操作。
Details
- Author
- huangfeng19820712
- GitHub stars
- 21
- Downloads
- 438
- Categories
- Database
Jump to
- Secure connection handling with automatic cleanup
- Prepared statement support to prevent SQL injection
- Comprehensive error handling and validation
- TypeScript support
- Automatic connection management
- Tools for querying, executing DML, and schema inspection
Setting up with Highlight
This MCP is not yet compatible with Highlight’s one-click setup. However, you can still use it with Highlight by following these steps:
- Download and install Highlight from highlightai.com/download
- Navigate to the plugins tab and select "Add Custom Plugin"
-
Configure the plugin with the settings below
Plugin Name
Mcp Mysql ServerCommand (node, npx, python, etc.)Please refer to the README for specific instructions on how to obtain API keys or other required environment variables.
- Enable "Start Automatically" if you want the plugin to start when Highlight launches
From the repository
Install via Smithery (npx -y @smithery/cli install @fhuang/mcp-mysql-server --client claude) or manually (npx @fhuang/mcp-mysql-server). Configure with a connection string or environment variables (MYSQL_HOST, MYSQL_USER, MYSQL_PASSWORD, MYSQL_DATABASE). Use tools like connect_db, query, execute, list_tables, describe_table, show_statement, and explain.
connect_db
Connect to MySQL database
query
Execute a SELECT query,can not get table structure,use describe_table tool to get table structure
execute
Execute an INSERT, UPDATE, or DELETE query
list_tables
List all tables in the database
describe_table
Get table structure
show_statement
Execute a SHOW statement (e.g., SHOW STATUS, SHOW VARIABLES)
explain
Analyze SQL query performance using EXPLAIN
Claude Desktop / Cursor
Paste into your MCP client config file to install this server.
{
"mcpServers": {
"mcp mysql server": {
"mysql": {
"command": "npx",
"args": [
"-y",
"@fhuang/mcp-mysql-server"
],
"env": {
"MYSQL_HOST": "IP",
"MYSQL_USER": "USER",
"MYSQL_PORT": "PORT",
"MYSQL_PASSWORD": "password",
"MYSQL_DATABASE": "DATABASE"
}
}
}
}
}McpServers
{
"mysql": {
"command": "npx",
"args": [
"-y",
"@fhuang/mcp-mysql-server"
],
"env": {
"MYSQL_HOST": "IP",
"MYSQL_USER": "USER",
"MYSQL_PORT": "PORT",
"MYSQL_PASSWORD": "password",
"MYSQL_DATABASE": "DATABASE"
}
}
}@fhuang/mcp-mysql-server
---
> For Chinese documentation, please see README.zh-CN.md
---
A Model Context Protocol server that provides MySQL database operations. This server enables AI models to interact with MySQL databases through a standardized interface.
Installation
Installing via Smithery
To install MySQL Server for Claude Desktop automatically via Smithery:
npx -y @smithery/cli install @fhuang/mcp-mysql-server --client claude
Manual Installation
npx @fhuang/mcp-mysql-server
Configuration
The server requires the following environment variables to be set in your MCP settings configuration file:
> recommended use
{
"mcpServers": {
"mysql": {
"command": "npx",
"args": ["-y", "@fhuang/mcp-mysql-server", "mysql://user:password@localhost:port/database"],
}
}
}
{
"mcpServers": {
"mysql": {
"command": "npx",
"args": ["-y", "@fhuang/mcp-mysql-server"],
"env": {
"MYSQL_HOST": "your_host",
"MYSQL_USER": "your_user",
"MYSQL_PASSWORD": "your_password",
"MYSQL_DATABASE": "your_database"
}
}
}
}
Running evals
The evals package loads an mcp client that then runs the index.ts file, so there is no need to rebuild between tests. You can load environment variables by prefixing the npx command. Full documentation can be found here.
OPENAI_API_KEY=your-key npx mcp-eval src/evals/evals.ts src/index.ts
Available Tools
1. connect_db
Establish connection to MySQL database using provided credentials.use_mcp_tool({
server_name: "mysql",
tool_name: "connect_db",
arguments: {
host: "localhost",
user: "your_user",
password: "your_password",
database: "your_database"
}
});
2. query
Execute SELECT queries with optional prepared statement parameters.use_mcp_tool({
server_name: "mysql",
tool_name: "query",
arguments: {
sql: "SELECT FROM users WHERE id = ?",
params: [1]
}
});
3. execute
Execute INSERT, UPDATE, or DELETE queries with optional prepared statement parameters.use_mcp_tool({
server_name: "mysql",
tool_name: "execute",
arguments: {
sql: "INSERT INTO users (name, email) VALUES (?, ?)",
params: ["John Doe", "john@example.com"]
}
});
4. list_tables
List all tables in the connected database.use_mcp_tool({
server_name: "mysql",
tool_name: "list_tables",
arguments: {}
});
5. describe_table
Get the structure of a specific table.use_mcp_tool({
server_name: "mysql",
tool_name: "describe_table",
arguments: {
table: "users"
}
});
6. show_statement
执行 SHOW 语句（如 SHOW STATUS, SHOW VARIABLES 等）。use_mcp_tool({
server_name: "mysql",
tool_name: "show_statement",
arguments: {
sql: "SHOW VARIABLES"
}
});
7. explain
Analyze SQL query performance using EXPLAIN. Returns execution plan details including access type, rows examined, and possible optimizations.use_mcp_tool({
server_name: "mysql",
tool_name: "explain",
arguments: {
sql: "SELECT FROM users WHERE id = ?"
}
});
Features
- Secure connection handling with automatic cleanup
- Prepared statement support for query parameters
- Comprehensive error handling and validation
- TypeScript support
- Automatic connection management
Security
- Uses prepared statements to prevent SQL injection
- Supports secure password handling through environment variables
- Validates queries before execution
- Automatically closes connections when done
Error Handling
The server provides detailed error messages for common issues:
- Connection failures
- Invalid queries
- Missing parameters
- Database errors
Contributing
Contributions are welcome! Please feel free to submit a Pull Request to https://github.com/huangfeng19820712/mcp-mysql-server
License
MIT
