mcp_mysql_server
About
Model Context Protocol (MCP) server that supports secure interaction with MySQL databases and has anomaly analysis capabilities.更加牛逼！更加好用！不仅止于mysql的增删改查功能； 还包含了数据库异常分析能力；且便于开发者们进行个性化的工具扩展
Details
- License
- MIT
Explore
- Supports all MCP transfer modes (STDIO, SSE, Streamable Http)
- Includes SQL execution, health analysis, lock detection, and index usage tools
- Provides permission control with readonly, writer, and admin roles
- Supports OAuth2.0 authentication for secure access
- Allows custom tool extension by adding new handler classes
- Converts Chinese field names to pinyin initials
Setting up with Highlight
This MCP is not yet compatible with Highlight’s one-click setup. However, you can still use it with Highlight by following these steps:
- Download and install Highlight from highlightai.com/download
- Navigate to the plugins tab and select "Add Custom Plugin"
-
Configure the plugin with the settings below
Plugin Name
mcp_mysql_serverCommand (node, npx, python, etc.)Please refer to the README for specific instructions on how to obtain API keys or other required environment variables.
- Enable "Start Automatically" if you want the plugin to start when Highlight launches
From the repository
- Table name: department
- Common fields need indexes
- Each field needs comments, table needs comment
- Generate 5 real data records after creation
2. Query data based on table comments, prompt as follows:
Search for data with Department name 'Executive Office' in Department organizational structure table
3. Analyze slow SQL, prompt as follows:
select * from t_jcsjzx_hjkq_cd_xsz_sk xsz
left join t_jcsjzx_hjkq_jcd jcd on jcd.cddm = xsz.cddm
Based on current index situation, review execution plan and provide optimization suggestions in markdown format, including table index status, execution details, and optimization recommendations
4. Analyze SQL deadlock issues, prompt as follows:
update t_admin_rms_zzjg set sfyx = '0' where xh = '1' is stuck, please analyze the cause
5. Analyze the health status prompt as follows
Check the current health status of MySQL
1. Install Package
pip install mysql_mcp_server_pro
2. Configure Environment Variables
Create a .env file with the following content:
MYSQL_HOST=localhost
MYSQL_PORT=3306
MYSQL_USER=your_username
MYSQL_PASSWORD=your_password
MYSQL_DATABASE=your_database
mysql_mcp_server_pro --oauth true
4. mcp client
go to see see "Use uv to start the service"
^_^
Note:
- The .env file should be placed in the directory where you run the command or use --envfile parameter to specify the path
- You can also set these variables directly in your environment
- Make sure the database configuration is correct and can connect
- This method can be used directly in MCP-supported clients, no need to download the source code. For example, Tongyi Qianwen plugin, trae editor, etc.
{
"mcpServers": {
"mysql": {
"command": "uvx",
"args": [
"--from",
"mysql_mcp_server_pro",
"mysql_mcp_server_pro",
"--mode",
"stdio"
],
"env": {
"MYSQL_HOST": "192.168.x.xxx",
"MYSQL_PORT": "3306",
"MYSQL_USER": "root",
"MYSQL_PASSWORD": "root",
"MYSQL_DATABASE": "a_llm",
"MYSQL_ROLE": "admin"
}
}
}
}
uv run -m mysql_mcp_server_pro.server --oauth true
1. Start the authentication service. By default, it uses the built-in OAuth 2.0 password mode authentication. You can modify your own authentication service address in the env file.
uv run -m mysql_mcp_server_pro.server --oauth true
2. Visit the authentication service at http://localhost:3000/login. Default username and password are configured in the env file.
3. Copy the token and add it to the request headers, for example:
{
"mcpServers": {
"mysql_mcp_server_pro": {
"name": "mysql_mcp_server_pro",
"type": "streamableHttp",
"description": "",
"isActive": true,
"url": "http://localhost:3000/mcp/",
"headers": {
"authorization": "bearer TOKEN_VALUE"
}
}
}
}
execute_sql
SQL execution tool that can execute ["SELECT", "SHOW", "DESCRIBE", "EXPLAIN", "INSERT", "UPDATE", "DELETE", "CREATE", "ALTER", "DROP", "TRUNCATE"] commands based on permission configuration
get_chinese_initials
Convert Chinese field names to pinyin initials
get_db_health_running
Analyze MySQL health status (connection status, transaction status, running status, lock status detection)
get_table_desc
Search for table structures in the database based on table names, supporting multi-table queries
get_table_index
Search for table indexes in the database based on table names, supporting multi-table queries
get_table_lock
Check if there are row-level locks or table-level locks in the current MySQL server
get_table_name
Search for table names in the database based on table comments and descriptions
get_db_health_index_usage
Get the index usage of the currently connected mysql database, including redundant index situations, poorly performing index situations, and the top 5 unused index situations with query times greater than 30 seconds
optimize_sql
Professional SQL performance optimization tool, providing expert optimization suggestions based on MySQL execution plans, table structure information, table data volume, and table indexes.
use_prompt_queryTableData
Use built-in prompts to let the model construct a chain call of tools in mcp (not a commonly used fixed tool, you need to modify the code to enable it, see this class for details)
| Tool Name | Description |
|----------------------------|--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------|
| execute_sql | SQL execution tool that can execute ["SELECT", "SHOW", "DESCRIBE", "EXPLAIN", "INSERT", "UPDATE", "DELETE", "CREATE", "ALTER", "DROP", "TRUNCATE"] commands based on permission configuration |
| get_chinese_initials | Convert Chinese field names to pinyin initials |
| get_db_health_running | Analyze MySQL health status (connection status, transaction status, running status, lock status detection) |
| get_table_desc | Search for table structures in the database based on table names, supporting multi-table queries |
| get_table_index | Search for table indexes in the database based on table names, supporting multi-table queries |
| get_table_lock | Check if there are row-level locks or table-level locks in the current MySQL server |
| get_table_name | Search for table names in the database based on table comments and descriptions |
| get_db_health_index_usage | Get the index usage of the currently connected mysql database, including redundant index situations, poorly performing index situations, and the top 5 unused index situations with query times greater than 30 seconds |
| optimize_sql | Professional SQL performance optimization tool, providing expert optimization suggestions based on MySQL execution plans, table structure information, table data volume, and table indexes. |
| use_prompt_queryTableData | Use built-in prompts to let the model construct a chain call of tools in mcp (not a commonly used fixed tool, you need to modify the code to enable it, see this class for details) |
Claude Desktop / Cursor
Paste into your MCP client config file to install this server.
{
"mcpServers": {
"mcp_mysql_server": {
"mysql": {
"command": "uvx",
"args": [
"--from",
"mysql_mcp_server_pro",
"mysql_mcp_server_pro",
"--mode",
"stdio"
],
"env": {
"MYSQL_HOST": "",
"MYSQL_PORT": "",
"MYSQL_USER": "",
"MYSQL_PASSWORD": "",
"MYSQL_DATABASE": "",
"MYSQL_ROLE": ""
}
}
}
}
}McpServers
{
"mysql": {
"command": "uvx",
"args": [
"--from",
"mysql_mcp_server_pro",
"mysql_mcp_server_pro",
"--mode",
"stdio"
],
"env": {
"MYSQL_HOST": "",
"MYSQL_PORT": "",
"MYSQL_USER": "",
"MYSQL_PASSWORD": "",
"MYSQL_DATABASE": "",
"MYSQL_ROLE": ""
}
}
}Introduction
mcp_mysql_server_pro is not just about MySQL CRUD operations, but also includes database anomaly analysis capabilities and makes it easy for developers to extend with custom tools.- Supports all Model Context Protocol (MCP) transfer modes (STDIO, SSE, Streamable Http)
- Supports OAuth2.0
- Supports multiple SQL execution, separated by ";"
- Supports querying database table names and fields based on table comments
- Supports SQL execution plan analysis
- Supports Chinese field to pinyin conversion
- Supports table lock analysis
- Supports database health status analysis
- Supports permission control with three roles: readonly, writer, and admin
"readonly": ["SELECT", "SHOW", "DESCRIBE", "EXPLAIN"], # Read-only permissions
"writer": ["SELECT", "SHOW", "DESCRIBE", "EXPLAIN", "INSERT", "UPDATE", "DELETE"], # Read-write permissions
"admin": ["SELECT", "SHOW", "DESCRIBE", "EXPLAIN", "INSERT", "UPDATE", "DELETE",
"CREATE", "ALTER", "DROP", "TRUNCATE"] # Administrator permissions
- Supports prompt template invocation
Tool List
| Tool Name | Description | |----------------------------|--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------| | execute_sql | SQL execution tool that can execute ["SELECT", "SHOW", "DESCRIBE", "EXPLAIN", "INSERT", "UPDATE", "DELETE", "CREATE", "ALTER", "DROP", "TRUNCATE"] commands based on permission configuration | | get_chinese_initials | Convert Chinese field names to pinyin initials | | get_db_health_running | Analyze MySQL health status (connection status, transaction status, running status, lock status detection) | | get_table_desc | Search for table structures in the database based on table names, supporting multi-table queries | | get_table_index | Search for table indexes in the database based on table names, supporting multi-table queries | | get_table_lock | Check if there are row-level locks or table-level locks in the current MySQL server | | get_table_name | Search for table names in the database based on table comments and descriptions | | get_db_health_index_usage | Get the index usage of the currently connected mysql database, including redundant index situations, poorly performing index situations, and the top 5 unused index situations with query times greater than 30 seconds | | optimize_sql | Professional SQL performance optimization tool, providing expert optimization suggestions based on MySQL execution plans, table structure information, table data volume, and table indexes. | | use_prompt_queryTableData | Use built-in prompts to let the model construct a chain call of tools in mcp (not a commonly used fixed tool, you need to modify the code to enable it, see this class for details) |Prompt List
| Prompt Name | Description | |---------------------------|---------------------------------------------------------------------------------------------------------------------------------------| | analyzing-mysql-prompt | This is a prompt for analyzing MySQL-related issues | | query-table-data-prompt | This is a prompt for querying table data using tools. If description is empty, it will be initialized as a MySQL database query assistant |Usage Instructions
Installation and Configuration
1. Install Packagepip install mysql_mcp_server_pro
2. Configure Environment Variables
Create a .env file with the following content:
```bash
