pyATS MCP Server
About
Interact with network devices using Cisco's pyATS and Genie libraries for model-driven automation.
Details
- License
- MIT
Explore
- Over a dozen tools for show commands, config, and diagnostics
- Validates show commands against pipes/redirects/dangerous keywords
- Blocks config commands containing reload, erase, delete, etc.
- Dynamic test scripts run in a restricted sandbox
- All credentials live in .env — never in source code or testbed file
- Supports concurrent operations on multiple devices
Setting up with Highlight
This MCP is not yet compatible with Highlight’s one-click setup. However, you can still use it with Highlight by following these steps:
- Download and install Highlight from highlightai.com/download
- Navigate to the plugins tab and select "Add Custom Plugin"
-
Configure the plugin with the settings below
Plugin Name
pyATS MCP ServerCommand (node, npx, python, etc.)Please refer to the README for specific instructions on how to obtain API keys or other required environment variables.
- Enable "Start Automatically" if you want the plugin to start when Highlight launches
From the repository
git clone https://github.com/automateyournetwork/pyATS_MCP
cd pyATS_MCP
pip install -r requirements.txt
cp .env.example .env
{
"mcpServers": {
"pyats": {
"command": "docker",
"args": [
"run", "-i", "--rm",
"--env-file", "/absolute/path/to/.env",
"-v", "/absolute/path/to/testbed.yaml:/app/testbed.yaml",
"pyats-mcp-server"
]
}
}
}
{
"mcpServers": {
"pyats": {
"command": "python3",
"args": ["-u", "/path/to/pyats_mcp_server.py"],
"env": {
"PYATS_TESTBED_PATH": "/absolute/path/to/testbed.yaml"
}
}
}
}
```
---
uv venv .venv && uv pip install -r requirements-dev.txt
pyats_list_devices
List all devices in the testbed
pyats_search_devices
Fuzzy-search devices by name or alias
pyats_run_show_command
Run a validated show command; returns parsed JSON or raw output
pyats_run_show_command_on_multiple_devices
Run a show command across multiple devices concurrently
pyats_ping_from_network_device
Execute a ping from a network device
pyats_run_linux_command
Run a command on a Linux host
pyats_configure_device
Apply configuration commands with safety guardrails
pyats_configure_devices_multi
Apply configuration across multiple devices concurrently
pyats_configure_with_diff
Apply config and return a before/after diff
pyats_rollback_config
Roll back to the last saved configuration snapshot
pyats_device_health
Snapshot CPU, memory, interfaces, and routing state
pyats_get_neighbors
Retrieve CDP/LLDP neighbors
pyats_find_interface_by_ip
Find which interface owns a given IP address
pyats_run_dynamic_test
Execute a sandboxed pyATS test script
pyats_get_operation_log
Retrieve the in-memory operation log
| Tool | Description |
|------|-------------|
| pyats_list_devices | List all devices in the testbed |
| pyats_search_devices | Fuzzy-search devices by name or alias |
| pyats_run_show_command | Run a validated show command; returns parsed JSON or raw output |
| pyats_run_show_command_on_multiple_devices | Run a show command across multiple devices concurrently |
| pyats_ping_from_network_device | Execute a ping from a network device |
| pyats_run_linux_command | Run a command on a Linux host |
| pyats_configure_device | Apply configuration commands with safety guardrails |
| pyats_configure_devices_multi | Apply configuration across multiple devices concurrently |
| pyats_configure_with_diff | Apply config and return a before/after diff |
| pyats_rollback_config | Roll back to the last saved configuration snapshot |
| pyats_device_health | Snapshot CPU, memory, interfaces, and routing state |
| pyats_get_neighbors | Retrieve CDP/LLDP neighbors |
| pyats_find_interface_by_ip | Find which interface owns a given IP address |
| pyats_run_dynamic_test | Execute a sandboxed pyATS test script |
| pyats_get_operation_log | Retrieve the in-memory operation log |
---
Claude Desktop / Cursor
Paste into your MCP client config file to install this server.
{
"mcpServers": {
"pyats mcp server": {
"pyats": {
"command": "docker",
"args": [
"run",
"-i",
"--rm",
"-e",
"PYATS_TESTBED_PATH",
"-v",
"/absolute/path/to/testbed/folder:/app",
"pyats-mcp-server"
],
"env": {
"PYATS_TESTBED_PATH": "/app/testbed.yaml"
}
}
}
}
}McpServers
{
"pyats": {
"command": "docker",
"args": [
"run",
"-i",
"--rm",
"-e",
"PYATS_TESTBED_PATH",
"-v",
"/absolute/path/to/testbed/folder:/app",
"pyats-mcp-server"
],
"env": {
"PYATS_TESTBED_PATH": "/app/testbed.yaml"
}
}
}
MCP server that wraps Cisco pyATS and Genie, letting AI agents (Claude, LangGraph, etc.) run show commands, apply configuration, and query network state over STDIO using JSON-RPC 2.0.
> All communication is via STDIN/STDOUT — no HTTP ports, no REST endpoints.
---
Quick Start
```bash
