Model Context Protocol for Unreal Engine

by chongdashu

2k stars

1.8k downloads

Not rated

GitHub Website

About

Enable AI assistant clients like Cursor, Windsurf and Claude Desktop to control Unreal Engine through natural language using the Model Context Protocol (MCP).

Details

Author: chongdashu
GitHub stars: 2,022
Downloads: 1,809
Categories: AI, Developer Tools

Setting up with Highlight

This MCP is not yet compatible with Highlight’s one-click setup. However, you can still use it with Highlight by following these steps:

Download and install Highlight from highlightai.com/download
Navigate to the plugins tab and select "Add Custom Plugin"
Configure the plugin with the settings below

Plugin Name Model Context Protocol for Unreal Engine

Command (node, npx, python, etc.)

Please refer to the README for specific instructions on how to obtain API keys or other required environment variables.
Enable "Start Automatically" if you want the plugin to start when Highlight launches

Setting up with Cursor

Open Cursor's settings
Navigate to the MCP section
Click "Add new Global MCP server"
Copy and paste the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

Setting up with Claude Desktop

Open Claude Desktop's settings
Go to the Integrations tab
Click "Add MCP Server"
Use the configuration below based on your operating system

Note: Make sure Claude Desktop is running before attempting to connect.

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

Setting up with Windsurf

Open Windsurf's preferences
Go to the Integrations section
Click "Add MCP Integration"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

Setting up with Cline

Open Cline's settings
Navigate to the Integrations section
Click "Add MCP Server"
Copy and paste the configuration below based on your operating system

Note: Make sure to restart Cline after adding the configuration.

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

Setting up with Goose

Open Goose's preferences
Go to the Integrations tab
Select "MCP Servers"
Click "Add New Server"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

From the repository

You use the provided Unreal sample project or copy the plugin into your own project, enable the plugin, and build it. Then set up the Python server (requires Python 3.12+), and configure your MCP client (e.g., Claude Desktop, Cursor, Windsurf) with a JSON configuration pointing to unreal_mcp_server.py. The server communicates with the plugin over TCP (port 55557).

`set_unreal_engine_path`

Set the Unreal Engine path

`set_unreal_project_path`

Set the Project path

`get_unreal_engine_path`

Get the current Unreal Engine path

`get_unreal_project_path`

Get the current Unreal Project path

`editor_run_python`

Execute any python within the Unreal Editor. All python must have `import unreal` at the top. CHECK THE UNREAL PYTHON DOCUMENTATION BEFORE USING THIS TOOL. NEVER EVER ADD COMMENTS

`editor_list_assets`

List all Unreal assets Example output: [''/Game/Characters/Hero/BP_Hero'', ''/Game/Maps/TestMap'', ''/Game/Materials/M_Basic''] Returns a Python list of asset paths.

`editor_export_asset`

Export an Unreal asset to text Example output: Binary data of the exported asset file Returns the raw binary content of the exported asset.

`editor_get_asset_info`

Get information about an asset, including LOD levels for StaticMesh and SkeletalMesh assets Example output: [{'name': 'SM_Cube', 'is_valid': True, 'is_u_asset': True, 'is_asset_loaded': True, 'class': 'StaticMesh', 'path': '/Game/Meshes/SM_Cube', 'package': 'SM_Cube', 'package_path': '/Game/Meshes/SM_Cube', 'lod_levels': [{'lod_index': 0, 'num_vertices': 24, 'num_triangles': 12}, {'lod_index': 1, 'num_vertices': 16, 'num_triangles': 8}]}] Returns asset metadata with LOD information for mesh assets.

`editor_get_asset_references`

Get references for an asset Example output: [{'name': '/Game/Materials/M_Character.M_Character', 'class': 'Material'}, {'name': '/Game/Blueprints/BP_Player.BP_Player', 'class': 'Blueprint'}] Returns list of assets that reference the specified asset.

`editor_console_command`

Run a console command in Unreal Example output: (No output for most commands, executed silently) Executes the console command without returning output.

`editor_project_info`

Get detailed information about the current project Example output: {'project_name': 'MyGame', 'project_directory': '/Users/dev/MyGame/', 'engine_version': '5.3.0', 'total_assets': 1250, 'asset_locations': {'Game': 800, 'Engine': 450}, 'enhanced_input_enabled': true, 'input_actions': ['/Game/Input/IA_Move'], 'game_modes': ['/Game/Core/GM_Main'], 'characters': ['/Game/Characters/B_Hero'], 'maps': ['/Game/Maps/L_TestMap']} Returns comprehensive project metadata and asset counts.

`editor_get_map_info`

Get detailed information about the current map/level Example output: {'map_name': 'TestMap', 'map_path': '/Game/Maps/TestMap', 'total_actors': 45, 'actor_types': {'StaticMeshActor': 20, 'DirectionalLight': 1, 'PlayerStart': 1}, 'lighting': {'has_lightmass_importance_volume': false, 'directional_lights': 1, 'point_lights': 3, 'spot_lights': 0}, 'streaming_levels': 0, 'streaming_level_names': []} Returns current level information with actor counts and lighting details.

`editor_search_assets`

Search for assets by name or path with optional class filter Example output: {'search_term': 'character', 'asset_class_filter': 'Blueprint', 'total_matches': 3, 'assets': [{'name': 'BP_Character', 'path': '/Game/Characters', 'class': 'Blueprint', 'package_name': 'BP_Character'}, {'name': 'BP_EnemyCharacter', 'path': '/Game/Enemies', 'class': 'Blueprint', 'package_name': 'BP_EnemyCharacter'}]} Returns search results with asset details, limited to 50 results.

`editor_get_world_outliner`

Get all actors in the current world with their properties Example output: {'world_name': 'TestMap', 'total_actors': 45, 'actors': [{'name': 'StaticMeshActor_0', 'class': 'StaticMeshActor', 'location': {'x': 0.0, 'y': 0.0, 'z': 0.0}, 'rotation': {'pitch': 0.0, 'yaw': 0.0, 'roll': 0.0}, 'scale': {'x': 1.0, 'y': 1.0, 'z': 1.0}, 'is_hidden': false, 'folder_path': '/Meshes', 'components': ['StaticMeshComponent', 'SceneComponent']}]} Returns complete world outliner with all actors and their transform data.

`editor_validate_assets`

Validate assets in the project to check for errors Example output: {'total_validated': 100, 'valid_assets': [{'path': '/Game/Meshes/SM_Cube', 'class': 'StaticMesh', 'size': '1024'}], 'invalid_assets': [{'path': '/Game/Missing/Asset', 'error': 'Asset does not exist'}], 'validation_summary': {'valid_count': 95, 'invalid_count': 5, 'success_rate': 95.0}} Returns validation results with asset status and error details.

`editor_create_object`

Create a new object/actor in the world Example output: {'success': true, 'actor_name': 'StaticMeshActor_1', 'actor_label': 'MyCube', 'class': 'StaticMeshActor', 'location': {'x': 100.0, 'y': 200.0, 'z': 0.0}, 'rotation': {'pitch': 0.0, 'yaw': 45.0, 'roll': 0.0}, 'scale': {'x': 1.0, 'y': 1.0, 'z': 1.0}} Returns created actor details with final transform values.

`editor_update_object`

Update an existing object/actor in the world Example output: {'success': true, 'actor_name': 'StaticMeshActor_1', 'actor_label': 'UpdatedCube', 'class': 'StaticMeshActor', 'location': {'x': 150.0, 'y': 200.0, 'z': 50.0}, 'rotation': {'pitch': 0.0, 'yaw': 90.0, 'roll': 0.0}, 'scale': {'x': 2.0, 'y': 2.0, 'z': 2.0}} Returns updated actor details with new transform values.

`editor_delete_object`

Delete an object/actor from the world Example output: {'success': true, 'message': 'Successfully deleted actor: MyCube', 'deleted_actor': {'actor_name': 'StaticMeshActor_1', 'actor_label': 'MyCube', 'class': 'StaticMeshActor', 'location': {'x': 100.0, 'y': 200.0, 'z': 0.0}}} Returns deletion confirmation with details of the deleted actor.

`editor_take_screenshot`


`editor_move_camera`

Move the viewport camera to a specific location and rotation for positioning screenshots

Claude Desktop / Cursor

Paste into your MCP client config file to install this server.

{
    "mcpServers": {
        "model context protocol for unreal engine": {
            "unrealMCP": {
                "command": "uv",
                "args": [
                    "--directory",
                    "<path/to/the/folder/PYTHON>",
                    "run",
                    "unreal_mcp_server.py"
                ]
            }
        }
    }
}

McpServers

{
    "unrealMCP": {
        "command": "uv",
        "args": [
            "--directory",
            "<path/to/the/folder/PYTHON>",
            "run",
            "unreal_mcp_server.py"
        ]
    }
}

Model Context Protocol for Unreal Engine

unreal-mcp

</div>

This project enables AI assistant clients like Cursor, Windsurf and Claude Desktop to control Unreal Engine through natural language using the Model Context Protocol (MCP).

⚠️ Experimental Status

This project is currently in an EXPERIMENTAL state. The API, functionality, and implementation details are subject to significant changes. While we encourage testing and feedback, please be aware that:

- Breaking changes may occur without notice
- Features may be incomplete or unstable
- Documentation may be outdated or missing
- Production use is not recommended at this time

🌟 Overview

The Unreal MCP integration provides comprehensive tools for controlling Unreal Engine through natural language:

| Category | Capabilities |
|----------|-------------|
| Actor Management | • Create and delete actors (cubes, spheres, lights, cameras, etc.) • Set actor transforms (position, rotation, scale) • Query actor properties and find actors by name • List all actors in the current level |
| Blueprint Development | • Create new Blueprint classes with custom components • Add and configure components (mesh, camera, light, etc.) • Set component properties and physics settings • Compile Blueprints and spawn Blueprint actors • Create input mappings for player controls |
| Blueprint Node Graph | • Add event nodes (BeginPlay, Tick, etc.) • Create function call nodes and connect them • Add variables with custom types and default values • Create component and self references • Find and manage nodes in the graph |
| Editor Control | • Focus viewport on specific actors or locations • Control viewport camera orientation and distance |

All these capabilities are accessible through natural language commands via AI assistants, making it easy to automate and control Unreal Engine workflows.

🧩 Components

Sample Project (MCPGameProject) `MCPGameProject`

- Based off the Blank Project, but with the UnrealMCP plugin added.

Plugin (UnrealMCP) `MCPGameProject/Plugins/UnrealMCP`

- Native TCP server for MCP communication - Integrates with Unreal Editor subsystems - Implements actor manipulation tools - Handles command execution and response handling

Python MCP Server `Python/unreal_mcp_server.py`

- Implemented in unreal_mcp_server.py - Manages TCP socket connections to the C++ plugin (port 55557) - Handles command serialization and response parsing - Provides error handling and connection management - Loads and registers tool modules from the tools directory - Uses the FastMCP library to implement the Model Context Protocol

📂 Directory Structure

- MCPGameProject/ - Example Unreal project
- Plugins/UnrealMCP/ - C++ plugin source
- Source/UnrealMCP/ - Plugin source code
- UnrealMCP.uplugin - Plugin definition

- Python/ - Python server and tools
- tools/ - Tool modules for actor, editor, and blueprint operations
- scripts/ - Example scripts and demos

- Docs/ - Comprehensive documentation
- See Docs/README.md for documentation index

🚀 Quick Start Guide

Prerequisites

- Unreal Engine 5.5+ - Python 3.12+ - MCP Client (e.g., Claude Desktop, Cursor, Windsurf)

Sample project

For getting started quickly, feel free to use the starter project in MCPGameProject. This is a UE 5.5 Blank Starter Project with the UnrealMCP.uplugin already configured.

1. Prepare the project
- Right-click your .uproject file
- Generate Visual Studio project files
2. Build the project (including the plugin)
- Open solution (.sln)
- Choose Development Editor as your target.
- Build

Plugin

Otherwise, if you want to use the plugin in your existing project:

1. Copy the plugin to your project
- Copy MCPGameProject/Plugins/UnrealMCP to your project's Plugins folder

2. Enable the plugin
- Edit > Plugins
- Find "UnrealMCP" in Editor category
- Enable the plugin
- Restart editor when prompted

3. Build the plugin
- Right-click your .uproject file
- Generate Visual Studio project files
- Open solution (.sln) - Build with your target platform and output settings


Python Server Setup
See Python/README.md for detailed Python setup instructions, including:

- Setting up your Python environment

- Running the MCP server

- Using direct or server-based connections
Configuring your MCP Client
Use the following JSON for your mcp configuration based on your MCP client.
{
  "mcpServers": {
    "unrealMCP": {
      "command": "uv",
      "args": [
        "--directory",
        "<path/to/the/folder/PYTHON>",
        "run",
        "unreal_mcp_server.py"
      ]
    }
  }
}

An example is found in mcp.json


MCP Configuration Locations
Depending on which MCP client you're using, the configuration file location will differ:

| MCP Client | Configuration File Location | Notes | |------------|------------------------------|-------| | Claude Desktop |~/.config/claude-desktop/mcp.json | On Windows: %USERPROFILE%\.config\claude-desktop\mcp.json| | Cursor |.cursor/mcp.json| Located in your project root directory | | Windsurf |~/.config/windsurf/mcp.json | On Windows: %USERPROFILE%\.config\windsurf\mcp.json` |

Each client uses the same JSON format as shown in the example above.
Simply place the configuration in the appropriate location for your MCP client.

License

MIT

Questions

For questions, you can reach me on X/Twitter: @chongdashu

No reviews yet — be the first

Use Google, GitHub, or an email account so ratings stay tied to real people.

Email sign in

No reviews posted yet.

About

Details

Jump to

Setting up with Highlight

From the repository

set_unreal_engine_path

set_unreal_project_path

get_unreal_engine_path

get_unreal_project_path

editor_run_python

editor_list_assets

editor_export_asset

editor_get_asset_info

editor_get_asset_references

editor_console_command

editor_project_info

editor_get_map_info

editor_search_assets

editor_get_world_outliner

editor_validate_assets

editor_create_object

editor_update_object

editor_delete_object

editor_take_screenshot

editor_move_camera

Claude Desktop / Cursor

McpServers

Model Context Protocol for Unreal Engine

⚠️ Experimental Status

🌟 Overview

🧩 Components

Sample Project (MCPGameProject) MCPGameProject

Plugin (UnrealMCP) MCPGameProject/Plugins/UnrealMCP

Python MCP Server Python/unreal_mcp_server.py

📂 Directory Structure

🚀 Quick Start Guide

Prerequisites

Sample project

Plugin

Python Server Setup

Configuring your MCP Client

MCP Configuration Locations

License

Questions

Install

More like this

Sentry

Github

Git

GitLab

Context 7

1Panel

`set_unreal_engine_path`

`set_unreal_project_path`

`get_unreal_engine_path`

`get_unreal_project_path`

`editor_run_python`

`editor_list_assets`

`editor_export_asset`

`editor_get_asset_info`

`editor_get_asset_references`

`editor_console_command`

`editor_project_info`

`editor_get_map_info`

`editor_search_assets`

`editor_get_world_outliner`

`editor_validate_assets`

`editor_create_object`

`editor_update_object`

`editor_delete_object`

`editor_take_screenshot`

`editor_move_camera`

Sample Project (MCPGameProject) `MCPGameProject`

Plugin (UnrealMCP) `MCPGameProject/Plugins/UnrealMCP`

Python MCP Server `Python/unreal_mcp_server.py`
