VAST DB MCP Server

This project implements a Model Context Protocol (MCP) server designed to act as an interface between AI agents/LLMs and a VAST Data database.

Project Goal

To provide a secure and structured way for AI models to query information (schema, data samples) and execute read-only queries against a VAST DB instance using the MCP standard.

Core Technology

Python: >=3.9
MCP SDK: modelcontextprotocol/python-sdk (mcp-sdk)
VAST DB SDK: vast-data/vastdb_sdk (vastdb)
ASGI Server: uvicorn
MCP Implementation: FastMCP from the mcp-sdk
Configuration: python-dotenv
Testing: pytest, pytest-asyncio, pytest-mock, httpx
Rate Limiting: slowapi

Project Structure

/
├── sdk/                     # Cloned SDKs (ignored by git)
│   ├── python-sdk/
│   └── vastdb_sdk/
├── src/
│   └── vast_mcp_server/     # Main Python package
│       ├── __init__.py
│       ├── server.py          # FastMCP application setup
│       ├── config.py          # Loads connection details from .env
│       ├── utils.py           # Shared utility functions (e.g., auth header extraction)
│       ├── resources/         # MCP Resource handlers
│       │   ├── __init__.py
│       │   ├── schema.py      # Handler for vast://schemas
│       │   ├── table_data.py  # Handler for vast://tables/{table_name}
│       │   └── metadata.py    # Handler for vast://metadata/tables/{table_name}
│       ├── tools/             # MCP Tool handlers
│       │   ├── __init__.py
│       │   └── query.py       # Handler for vast_sql_query tool
│       └── vast_integration/  # VAST DB interaction logic
│           ├── __init__.py
│           └── db_ops.py      # Connection & query execution (async wrappers)
├── tests/                   # Pytest unit/integration tests
│   ├── __init__.py
│   ├── test_db_ops.py     # Tests for VAST DB interaction logic
│   ├── test_resources.py  # Tests for MCP resource handlers
│   └── test_tools.py      # Tests for MCP tool handlers
├── scripts/
│   └── run_server.py        # Script to start the server via uvicorn
├── .gitignore
├── .env.example             # Example environment file
├── README.md                # This file
└── pyproject.toml           # Project metadata and dependencies

Implemented MCP Features

Authentication: All resources and tools require the following HTTP headers to be sent with the request:
X-Vast-Access-Key: Your VAST DB access key.
X-Vast-Secret-Key: Your VAST DB secret key.
Failure to provide these headers, or providing invalid credentials, will result in an UNAUTHENTICATED (401) error response.

Rate Limiting: All resource and tool handlers are rate-limited based on the client IP address. The default limit is configurable via the MCP_DEFAULT_RATE_LIMIT environment variable (e.g., "10/minute", see .env.example). Exceeding the limit will result in a 429 Too Many Requests error.

Resource: Database Schema
URI: vast://schemas
Description: Returns a formatted string describing all discovered tables and their columns (name and type). Requires authentication headers.
Error Handling: Returns an McpResponse with an error status code (UNAUTHENTICATED, SERVICE_UNAVAILABLE, INTERNAL_SERVER_ERROR) and a plain text error message body (ERROR: [ErrorType] Message).
Resource: List Tables
URI: vast://tables?format=FMT
Description: Returns a list of available table names. Requires authentication headers.
Parameters:
format (string, optional, default: json): Output format (json or csv/'list'). csv or list returns a newline-separated string.
Format: JSON array of strings, or a newline-separated list.
Error Handling: Returns an McpResponse with an error status code (UNAUTHENTICATED, BAD_REQUEST, SERVICE_UNAVAILABLE, INTERNAL_SERVER_ERROR) and a formatted error body (JSON or plain text based on format).
Resource: Table Metadata
URI: vast://metadata/tables/{table_name}
Description: Returns detailed metadata for a specific table. Requires authentication headers. Attempts to include column name, data type, nullability (is_nullable: e.g., 'YES'/'NO'), key information (key: e.g., 'PRI'), and default value (default). Fields beyond name/type might be null if not available from the database introspection.
Format: JSON object containing table_name (string) and columns (list of objects, each potentially with name, type, is_nullable, key, default keys).
Example Response (Enhanced):

        {

          "table_name": "my_table",

          "columns": [

            {

              "name": "id",

              "type": "INTEGER",

              "is_nullable": "NO",

              "key": "PRI",

              "default": null

            },

            {

              "name": "data_column",

              "type": "VARCHAR",

              "is_nullable": "YES",

              "key": "",

              "default": "'Default Text'"

            },

            {

              "name": "timestamp",

              "type": "TIMESTAMP",

              "is_nullable": "YES",

              "key": null,

              "default": null

            }

          ]

        }



Error Handling: Returns an McpResponse with an error status code (UNAUTHENTICATED, NOT_FOUND, BAD_REQUEST, SERVICE_UNAVAILABLE, INTERNAL_SERVER_ERROR) and a JSON error body ({\"error\": ...}).
Resource: Table Sample Data
URI: vast://tables/{table_name}?limit=N&format=FMT
Description: Returns a sample of data from the specified table_name. Requires authentication headers.
Parameters:
limit (integer, optional, default: 10): Maximum number of rows.
format (string, optional, default: csv): Output format (csv or json).
Format: CSV or JSON string (array of objects), including header row for CSV.
Error Handling: Returns an McpResponse with an error status code (UNAUTHENTICATED, BAD_REQUEST, SERVICE_UNAVAILABLE, INTERNAL_SERVER_ERROR) and a formatted error body (JSON or plain text based on format).
Tool: SQL Query Executor
Name: vast_sql_query
Arguments:
sql (string, required): The SQL query to execute.
format (string, optional, default: csv): Output format (csv or json).
headers (dict, required): Dictionary containing request headers, must include X-Vast-Access-Key and X-Vast-Secret-Key.
Description: Executes the provided SQL query against VAST DB using credentials from the headers argument.
Format: Returns results as a CSV or JSON string (array of objects) or an error message string (JSON or plain text based on format).
Safety: Allowed statement types controlled by MCP_ALLOWED_SQL_TYPES env var (defaults to SELECT).
Error Handling: Returns a formatted error string (JSON or plain text) on failure. Errors include missing/invalid headers (AuthenticationError), disallowed query types (InvalidInputError), connection issues (DatabaseConnectionError), and query execution problems (QueryExecutionError).

AI Agent Interaction Notes

When integrating this MCP server with an AI agent framework (e.g., LangChain, LlamaIndex, custom agents), consider the following:

1. Agent Prompting/Configuration:
The agent's system prompt or configuration must include descriptions of the available resources and tools (similar to the "Implemented MCP Features" section above). This enables the LLM to choose the correct action based on user requests.
Since MCP lacks standard discovery, explicitly list the URIs (vast://schemas, vast://tables?..., vast://metadata/tables/{name}, vast://tables/{name}?....) and the tool name (vast_sql_query) with their capabilities.

2. Authentication Handling (Security Critical):
NEVER include VAST DB credentials (access_key, secret_key) in prompts sent to the LLM.
The agent's orchestrator (the code running the agent logic, not the LLM) is responsible for managing credentials.
Load credentials securely on the client-side (using environment variables, secrets managers like Vault/AWS/Azure/GCP Secrets Manager, etc.).
For Resources: When the LLM generates a target URI, the orchestrator must:
Retrieve the stored credentials.
Construct the headers dictionary: {'X-Vast-Access-Key': '...', 'X-Vast-Secret-Key': '...'}.
Map the vast:// URI scheme to the actual HTTP URL of the running MCP server (e.g., http://localhost:8088/).
Make the HTTP GET request using an MCP client or standard HTTP client, passing the constructed headers.
For Tools: When the LLM decides to use the vast_sql_query tool and provides the sql and format arguments, the orchestrator must:
Retrieve the stored credentials.
Construct the headers dictionary as above.
Inject this headers dictionary into the arguments passed to the tool execution function. The LLM should not generate the headers argument itself.

3. Request Construction:
The LLM needs to generate the correct URI path parameters ({table_name}) and query parameters (?format=, ?limit=) for resources.
The LLM generates the sql and format arguments for the vast_sql_query tool.

4. Response Handling:
The client-side agent code needs to handle different response Content-Types (e.g., text/plain, application/json, text/csv).
It must check response status codes (especially for resources) to detect errors (e.g., 401, 404, 500, 503).
It needs to parse error messages from the response body (plain text or JSON) and potentially report them back to the user or use them for retries/alternative actions.

Potential Next Steps

Implement robust logging. (Done)
Add unit tests. (Done)
Refine output formats (e.g., offer JSON alongside CSV). (Done)
Enhance error handling and reporting. (Done - basic custom exceptions and formatting)
Add more granular resources/tools (e.g., list only tables, get table metadata). (Done - list tables, table metadata)
Implement more sophisticated query validation/sandboxing for the vast_sql_query tool. (Done - using sqlparse)
Make query restrictions (e.g., allowing non-SELECT) configurable. (Done - via MCP_ALLOWED_SQL_TYPES env var)
Add integration tests that require a running VAST DB instance or mock server. (Done - Added ASGI/mocked tests for all current resources/tools)
Consider adding authentication/authorization layer if needed. (Done - Header-based authentication)
Refactor shared code (e.g., extract_auth_headers, formatters) into utils.py. (Done)
Implement Rate Limiting. (Done - IP-based via slowapi on handlers)*

How to Run

1. Clone the repository (if you haven't already).
2. Set up Environment: Copy .env.example to .env and fill in your VAST DB endpoint, access key, and secret key.

    cp .env.example .env

    # Edit .env with your details



3. Install Dependencies: Using a virtual environment is recommended.
```
